Bone plates - Individualized implants for bone stabilization

Bone plates

Individualized implants for bone stabilization

In medical technology, the individualization of implants up to batch size 1 is increasing. New manufacturing processes enable more complex, sometimes very small structures. This poses new challenges for production and metrology.
The bone plates must be measured economically with high resolution and short measurement times.
With the Werth TomoScope® XS machines and the Werth longlife transmission sources used, threads and wall thicknesses on bone plates or the Torx drive of a screw can be measured reliably and quickly.

Please accept "Other" in the settings to watch this video.Werth Messtechnik
